Ultimate Series 8.0MP WDR Motorised HDCVI Bullet
Sale!
Ultimate Series 8.0MP WDR Motorised HDCVI Bullet
Ultimate Series 8.0MP WDR Motorised HDCVI Bullet
Ultimate Series 8.0MP WDR Motorised HDCVI Bullet

Ultimate Series 8.0MP WDR Motorised HDCVI Bullet

Original price was: $393.25.Current price is: $323.68.

(Guest - Inc. GST)
Register for Member Pricing

4 Interest Free Payments of $80.92
Ultimate Series 8.0MP WDR Motorised HDCVI Bullet

Add to wishlist

SKU: VSCVI8MPFBIRM Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

Experience unparalleled performance and ease of use with the Ultimate Series from Securview, with auto-iris motorised lens, true WDR, 100m infrared, dual voltage support and up to 700m Full HD video transmission.

Camera features:
• Streams up to Ultra HD 8.0MP (3840 x 2160)
• Motorised 3.7 ~ 11mm lens, auto iris
• Colour low light performance 0.01lx/F1.5 min illumination
• Up to 700m HD video transmission over coax
• Infrared illumination up to 100m
• IP67 rated for weather resistance
• High definition & standard definition dual outputs
• Alarm and audio I/O interface
• True WDR (120dB) & 3D noise reduction

Backwards compatible: HDCVI/Analogue dual BNC video outputs.
Analogue mode configuration via on-camera buttons, OSD using HDCVI DVR or tester.

Specification

Register for Member Pricing

Alarm Interface
2 channel in / 1 channel out

Analogue Support
Yes (Dual output)

Angle of View
112° (wide) ~ 46° (tele)

Audio Input
1 channel in

Camera Type
Bullet

Day/Night
Auto (ICR) / Colour / B&W

Detect (25px/m)
83m (wide) / 190m (tele)

Dimensions
273 x 95 x 95mm

Effective Pixels
1/3 ~ 1/100,000s

Electronic Shutter
1/3 ~ 1/30,000s

Focus
Auto/Manual Focus / 0.2m Min. Focus Distance

Frame Rate
12fps (8.0MP) / 25fps (4.0MP and lower)

Gain Control
Auto

Housing
Metal

Identify (250px/m)
8 (wide)/ 19m (tele)

Image Sensor
1/2” 8.0 Megapixel CMOS

Infrared Range
100m

Ingress Protection
IP67

Lens
3.7 ~ 11mm F1.5 Motorised Lens; Auto Iris

Lens Type
Motorised Varifocal

Lighting Compensation
BLC / WDR (120dB)

Max. Resolution
8.0 Megapixel

Minimum Illumination
0.01 Lux at F1.5 (Colour) / 0 Lux IR Active

Noise Reduction
2D / 3D

Observe (63px/m)
33m (wide) / 76m (tele)

Operating Environment
-30° to 60°C / RH95% (max)

OSD Menu
Support

Power Consumption
< 18.4W

Power Input
12VDC / 24VAC

Recognise (125px/m)
17m (wide)/ 38m (tele)

Resolution
8.0MP (3840 x 2160) to CIF (352 x 288)

Signal Noise Ratio
> 65dB

Synchronisation
Internal

Transmission Distance
Rated for up to 700m via 75-3 coaxial cable (performed in ideal test conditions)

Tri-Axis Mounting
No

Vandal Resistant
N/A

Video Output
2 x BNC video output (1 x HDCVI / 1 x Composite SD)

Weight
1.08kg

White Balance
Auto

Documents

Download the brochure from the link below.

 Brochure

 Quick Install Guide
