IVSEC NVR, 8 Ch, 12MP, 8 PoE+ Ports, 1 Bay, H265, 4K HDMI, IVS
Sale!

IVSEC NVR, 8 Ch, 12MP, 8 PoE+ Ports, 1 Bay, H265, 4K HDMI, IVS

Original price was: $495.00.Current price is: $490.05.

(Guest - Inc. GST)
Register for Member Pricing

4 Interest Free Payments of $122.51
iVSEC NVR with 8 PoE ports, 12MP recording capability per channel, up to 16TB storage, and advanced IVS to match cameras with facial detection, human and vehicle detection

Add to wishlist

SKU: IVNR308XC Categories: , Tag:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

The IVSEC NR308XC is a network video recorder (NVR) capable of supporting up to 8 IP security cameras and of recording at up to 12 megapixel resolution.When used with IVSEC X series cameras, installation is plug and play.

This NVR is fully ONVIF 2.6 compatible and can also support other brands of IP cameras.

Thanks to the 8 built-in PoE+ ports, you can save on installation costs. They supply both data and power directly to the cameras via a standard CAT5 or CAT6 network cable.

Remotely view footage from your security cameras (live or playback) over the internet via your PC, mobile, or tablet. Easily setup the app by simply scanning the QR code which is on your IVSEC network video recorder.

Register for Member Pricing

The NR308XC NVR can have up to 16TB storage (HDD not included). We recommend the use of surveillance grade HDD.

The NR308XC features H.265 video compression, the most up to date video compression technology. This will save storage space and network bandwidth.

This NR308XC comes with a free VMS software which allows you to access the NVR from compatible Windows or Mac OS computers, either locally or via the cloud (simply scan the QR code).

Register for Member Pricing

Key Features:

  • Supports up to 8MP cameras
  • 8 built in PoE+ ports
  • Extended PoE on ports for up to 250m cable runs to iVSEC cameras
  • H265
  • ONVIF 2.6 compatible
  • Fanless design for very quiet operation
  • up to 16TB Storage
  • Gigabit interface
  • Save a snapshot or a video segment to cloud (Dropbox or FTP)
  • Video search methods include: Continuous, Scheduling, Event Triggered ( PIR, IVS, Motion, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Pedestrian Detection, Face Detection, Cross Counting)
  • HTTPS support for higher cyber security
  • Automatic firmware updates via FTP
  • 2 year warranty

NR308XC Specifications

Maximum Channels
8

Max Video Resolution (MP)
12

Examples of Channels at resolution FPS
128 Mbps

Video Compression
H.265+, H.265, H.264+, H.264

Video Output Resolution
4K, HD-1080p, HD-720p, 1.3 MP, D1, VGA

Display Layout
1 / 4 / 6 / 8 / 9

Search Method
Continuous, Scheduling, Event Triggered ( PIR, IVS, Motion, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Pedestrian Detection, Face Detection, Cross Counting)

Total Storage (TB)
16

HDD Bays Size
Bays x 1, up to 14TB HDD

Software
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app

Protocols
TCP, HTTP, HTTPS, DHCP, DDNS, NTP, SMTP, PPPOE, RTSP, UPnP, ONVIF, P2P, QR Code

Language
English, French, Dutch, German, Italian, Polish, Portuguese, Spanish, Thai, Turkish, Hungarian, Simplified Chinese, etc

Audio Streaming
Out

PoE Built in Switch
8 up to 802.3at(30w)

Power Supply
DC48V/2A 8W (excl. cameras and HDD)

Connectors
HDD: 3.5″ SATA HDD Slot x 1, USB2 Female x 2, USB3 Female x 1, Gigabit Ethernet: RJ-45 Port x 1 and 8 x PoE+ ports, HDMI and VGA, Alarm ports 8 in and 1 out, Audio out, Power Jack input, On off switch

Operating Environment
5ºC to 45ºC (41ºF-113ºF) Humidity: 20%-80% RH

In The Box
Printed quick installation guide, Mouse, Remote control, HDD screws, Power supply.

Model
NR308XC

Weight
1000

Warranty
24 months parts & labour warranty

Dimensions
300x227x53 mm

Register for Member Pricing

Ask a Question

Please ask questions you may have about this product or your project in the form below

Ask a question about this item

Documents

Download documents from the following links:

IVNR308XB-datasheet
