Shop » Products » IP CCTV » Provision-ISR IP CCTV » IP EYE-SIGHT-V2 » 60M IR 2MP Motorised Vari-Focal Bullet – I6-320IPEN-MVF
License Plate Recognition LPR Motorized VF Bullet- I6-320LPR-MVF1
License Plate Recognition LPR Motorized VF Bullet- I6-320LPR-MVF1

60M IR 2MP Motorised Vari-Focal Bullet – I6-320IPEN-MVF

Login, Register, or Call for Price

Register for Member Pricing

2MP IP Camera • 60m IR Range • NDAA Certified • Eye-Sight v2 Series • Real-Time • 2.8-12mm Motorized Vari-Focal Lens • DDA Object Detection • Face Detection
SKU: I6-320IPEN-MVF Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

60m IR 2MP DDA Analytics Motorized Lens Large Bullet Camera

Equipped with a 2.8-12mm motorized lens, this 2MP bullet camera is designed for long-distance surveillance (up to 60m) in indoor and outdoor scenarios.

The camera offers broad possibilities for Analytics, from Face Detection to the outstanding DDA Analytics (Detect, Distinguish, Alert), which can perform object recognition and object counting. With various detection rules and triggers, the I6-320IPEN-MVF camera will help end false alarms.

Israeli made professional high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

Register for Member Pricing

I6-320IPEN-MVF-features

I6-320IPEN-MVF Features

3rd Party Cyber Protection

General
N/A
Protection Methods
N/A

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/3″ CMOS (16:9)
Effective Pixels
1920×1080
Electronic Shutter
1/25s ~ 1/100000s
Day & Night
ICR
Min. Illumination
Day: 0.1lux / Night: 0.005lux (@F1.6, AGC on) 0lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
Two-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR (120dB), BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes

Events and Analytics

Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing, DDA Object Counting (Line), DDA Object Counting (Area), DDA Loitering Detection, DDA Illegal Parking Detection AI (Face Detection): 10 Faces per frame AI: Heatmap DDA2: Advanced Object Classification Audio Exception
Motion Detection
Yes

Compression

Resolution
2MP / 1MP / D1 (704×576) / QVGA (480×240) / CIF (352×288)
Frame Rate
1-25/30FPS In Normal Mode. 1-50/60FPS in HFR Mode***
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Master Stream: 2MP (1920×1080) / 1MP (1280×720) (1~30fps) Substream: 1MP/QVGA/D1/CIF Third Stream: QVGA/D1/CIF (1~30fps)
Bit Rate
64Kbps ~ 4Mbps@H.265 / 64Kbps ~ 6Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
2.8-12mm MVF with Auto Focus (103°-32°)
Iris
DC Iris
Lens Mount
Ø14 Mount

Network

User Access
Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile T/S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Audio input + Audio output
Alarm
Alarm in + Alarm out
SD Card
Event/Schedule based Main/Substream recording (Up to 128Gb)
Wiegand
No
Power
DC Socket
Analog Video Output
CVBS out + Technician Port

Housing

PoE
Yes
Illumination
60m (4 High-Power IR LED)
Power Supply
DC12V/~910mA / PoE/~8.2W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
3-Axis Bracket
Dimensions
271.8×92.4×79.4mm
Weight (gross)
~1040g
Hard Reset Button
Yes

Ask a Question

Please ask questions you may have about this product or your project in the form below

Ask a question about this item

Downloads

Documents

I6-320IPEN-MVF Datasheet

v5.x 320IPEN 340IPEN 380IPEN VF Series Manual

Software:

Latest CMS Version

Latest CMS for MAC

Latest IP Tool

DORI Distance

DORI Distance

(Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)

Model
I6-320IPEN-MVF

Detect (25px/m)
42.7m (Wide)
137m (Tele)

Observe (63px/m)
16.9m (Wide)
54m (Tele)

Recognise (125px/m)
8.5m (Wide)
27.5m (Tele)

Identify (250px/m)
4.2m (Wide)
13.7m (Tele)

Note: Wide is for minimum zoom and Tele is for Maximum Zoom

For more information on selecting a CCTV camera please see this post:

Choosing the right CCTV camera for your application.
