32CH 12MP Face Recognition NVR, 16 Ch PoE - NVR12-32800FN-16P(2U)
32CH 12MP Face Recognition NVR, 16 Ch PoE - NVR12-32800FN-16P(2U) - Image 2
32CH 12MP Face Recognition NVR, 16 Ch PoE - NVR12-32800FN-16P(2U) - Image 3
32CH 12MP Face Recognition NVR, 16 Ch PoE - NVR12-32800FN-16P(2U) - Image 4

32CH 12MP Face Recognition NVR, 16 Ch PoE – NVR12-32800FN-16P(2U)

Login, Register, or Call for Price

Register for Member Pricing

32 Channel (Via Network / 16 Port PoE) • 12MP AI • Output: HDMI (4K) + VGA • 2U Case, 8 x HDD with RAID • Audio In/Out • Alarm In/Out • 1000Mbps Network
SKU: NVR12-32800FN-16P(2U) Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

Input: 32 Channel (Via Network, 16 Port PoE) • Output: HDMI (4K), VGA • 2U Case • 8 x HDD with RAID • Audio In/Out • Alarm In/Out • 1000Mbps Network

This is a 32 Channel AI NVR capable of recording cameras up to 12MP. Record 32 channels of up to 12MP with analytics – Face Recognition, Smart Search, Camera Tampering, Line Crossing, Sterile Area, Object Monitoring.

The device features 16 alarm inputs + 4 alarm outputs and supports Face Recognition and Advanced Video Analitycs (DDA). This easy-to-install solution is suitable for big-sized installations (up to 32 channels). It also complies with NDAA demands. Check Point Quantum IoT Nano agent is integrated into this model. It provides an advanced threat prevention layer against the common attack vectors at runtime.

Playback to 4K / HD  / VGA monitor in real time.

Register for Member Pricing

16 PoE ports are included on this model and maximum of 256Mb/s incoming or outgoing stream. A further 16 camera streams are added via LAN port (cameras require separate power) on NVR.

Install up to 8 surveillance grade Hard Disk Drives up to 8TB each with RAID 0/1/5/6/10 Support

Israeli made, professional, high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

nvr12-32800fn-16p2u-features

NVR12-32800FN-16P (2U) Features

3rd Party Cyber Protection

General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

NDAA Compliant
Yes

Video

Video Input
32Ch over Network (out of which up to 16Ch PoE Direct Connection)
Output
HDMI (4K@60Hz, 4K@30Hz, 1080P), VGA (1080P, 1280×1024, 1024×768)
View Mode
Independent*, Up to 32ch on monitor1 + 9ch on monitor2
Fish-Eye Dewarp
Local + Web
Decoding Format
H.265 / H.265+ / H.265S / H.264
Decoding Capabilities
1Ch – 12MP ; 4Ch – 2MP ; 9-32Ch – D1

Audio

Audio-specs-Input
1CH RCA (Linear, 1k?) + IPC inputs
audio-specs-Output
1CH RCA (2.0 Vp-p, 1 k?) + IPC Outputs
Compression
G.711A/G.711U
Two Way Audio
Yes

Analytics

Supported Analytics
Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, Face Recognition, LPR, Thermal. Advanced Face Recognition Mode: Supports up to 2 Non-AI IPC and performs face detection and recognition.
Analytics Channels (IPC Based)
32Ch (requires supporting IPC)
Analytic Channels (NVR Based)
Up to 2Ch DDA1 (Sterile Area/Line Crossing) or Up to 2Ch Face Detection + Recognition or Up to 6Ch Face Recognition (or their combinations)
Face Recognition Rate
18 Faces per second (6Ch supported)

Bandwidth

Incoming
192Mbps
Outgoing
192Mbps

Record/ Main Stream

Real-Time Recording
32CH 8MP Real-Time 12MP – 20FPS
Record Type
Video / Video + Audio
Recording Modes
Schedule, Manual, Motion, Sensor, Analytics, POS, and all of its combinations
16MP
N/A
12MP
640FPS(PAL/NTSC)
8MP
960FPS(NTSC)/800FPS(PAL)
5MP and lower
960FPS(NTSC)/800FPS(PAL)
Master stream over network
Up to 32CH@Recording resolution

Substream

Resolution substream
Depends on IPC

Remote view

Max Channel View
160Ch (Limited to Outgoing Bandwidth Capacity)

Remote Applications

User Access
128 Users online with Professional Autorithy Management
Mobile App
Provision Cam2 for iOS/Android
PC/Mac Software
Ossia VMS Standard / Enterprise
Plug-in free Web-Browser
Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View/Playback)
Plug-in based Web-Browser
Internet Exporer

Playback

Local
16Ch
Remote
32Ch on IE, 4Ch on H5
Search Mode
DDA Object, Smart Search, LPR, Face Recognition, Time-Slice, Time, Event, POS

Backup

USB
1 USB 2.0 Port + 1 USB 3.0 Port
Backup Format
AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)

Alarm

Alarm-in
16+IPC
Alarm-out
4+IPC

Storage

HDD
8
E-Sata Support
1
RAID
N/A

PTZ

Connection
Via Network
Supported Controls
Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485
Yes (C06 Keyboard Connection)

Network

Ethernet
2×1000/100/10Mbps self-adaptive Ethernet interface
Protocols
TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, FTP, HTTPS, 820.1X, SNMP, Auto Report (Ossia VMS)
ONVIF
Full Device Support (Profile T/G, ONVIF Version 20.12)

PoE

PoE Ports
16xRJ45
Speed
10/100Mbps (10Mbps Under CCTV Mode)
Standard
PoE (IEEE802.3AF)
CCTV Mode
Yes (Up to 200m and 10Mbps bandwidth)
Total Power
150W (Avarage 9.3W per Channel)
Max. Power Output (Per Ch.)
~15W*

Others

Power Supply
AC100-240V
Power consumption (No HDD)
30W
Dimension
W445xD436xH90mm
Operation Temperature
0°C~50°C
