Shop » Products » IP CCTV » VIP Vision / Watchguard » Network Video Recorder (NVR) » Professional AI Series 32CH PoE NVR with 4 x HDD Bays
Sale!
Professional AI 32 Channel Network Video Recorder with ePoE (320Mbps)

Professional AI Series 32CH PoE NVR with 4 x HDD Bays

Original price was: $2,644.07.Current price is: $2,316.61.

(Guest - Inc. GST)
Register for Member Pricing

Professional AI 32 Channel Network Video Recorder with ePoE (320Mbps)

Add to wishlist

SKU: NVR32PRO16P-I2 Categories: ,
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

The NVR32PRO16P-I2 offers advanced technologies to transform the way surveillance works for you. Monitor your operations with greater efficiency, security & reliability using face recognition and AI-powered people & vehicle detection. Identify strangers, set up face whitelists & blacklists, search playback by face and receive people and vehicle surveillance alerts to your devices.

Product Features:

  • Record beyond Ultra HD up to 16.0MP (4920 x 3264)
  • Up to 320Mbps incoming bandwidth, H.265+ support
  • Decode up to 4 channels at 4K / 16 channels at 1080p (30fps)
  • 4 x SATA 14TB HDD support for up to 56TB footage storage (HDD not included)
  • 16 x Built-in PoE switch (8 x ePoE ports, 800m@10Mbps using ePoE cameras)
  • Native Ultra HD live view on 4K monitors via HDMI
  • Identify people in real-time with up to 16 channels of face recognition (with Ultimate AI cameras)
  • AI-powered perimeter protection, up to 12 channels of people & vehicle detection
  • Receive face recognition & perimeter alerts on your device

Specification

Register for Member Pricing

AI Search (Face Recognition)
Up to 8 target face images at the same time

AI Search (Metadata)
Support search target video by metadata

AI Search (Perimeter Protection)
Search by target classification (Human, Vehicle)

Alarm Input / Output
16 channel Alarm inputs / 6 channel Relay Outputs

Auxiliary Inputs
1 x RS232, 1 x RS485

Backup Modes
USB Device / Network / eSATA Device

Database Application
Each database can be applied to video channels independently

Database Management
Up to 20 face databases with 200,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture

Decoding Capacity
4 channels: 8.0MP (30fps) / 16 channels: 1080p (30fps)

Dimensions
440mm x 411mm x 76mm

Display Resolution
Configurable from: HDMI 1/ VGA – 1920 x 1080 to 1024 x 768, HDMI 2- 3840 x 2160 to 1280 x 720

Display Split
1st screen – 1/4/8/9/16/25/36, 2nd screen – 1/4/8/9/16

Ethernet
1 RJ45 Port (10/100/1000Mbps)

Face
Gender, age, glasses, beard, mask

HDD Modes
N/A

Human Body
Tops style, tops colour, bottom style, bottom colour, hat , bag

Incoming Bandwidth
320Mbps (160Mbps when AI function is enabled)

Internal HDD
4 x SATA III Ports up to 10TB, max. 40TB HDD capacity

Interoperability
ONVIF 2.4, SDK, CGI

Main Processor
Multi-core embedded processor

Max. User Access
128 users

Network Functions
HTP, HTTPS, TCP/IP, IPv4/IPV6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPoE, DDNS, FTP, Alarm server, IP Search (supports VIP cameras/NVRs), P2P

Non-motor Vehicle
Type, colour, people, number

Object Classification
Human / vehicle secondary recognition for tripwire and intrusion

Operating Environment
-10°C ~ +55°C / 0 ~ 90%RH / 86 ~ 106kpa

Operating System
Embedded LINUX

Optical Interface
N/A

OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Performance (Face Recognition)
Max. 16 face pictures per second (modeling and comparing), Approx. 16 channels face recognition with Ultimate AI cameras / Approx. 4 channels face recognition with Professional AI & standard cameras (Performance varies depending on camera and resolution)

Performance (Perimeter Protection)
12 Channel, 10 IVS rules for each Channel

Playback Sync
1/4/9/16

PoE
Yes, w/ePoE

Power Consumption
<21.1W (without HDD) / PoE: 25.5W per port, 150W total

Power over Ethernet
16 Ports (IEE802.3af/at), 1-8 Ports Support ePoE & EoC

Power Supply
Single, AC100V~240V, 50~60 Hz

Rackmount Units
1.5RU

Rackmountable
Yes (included)

Record Interval
1~120 min (default: 60 min) / Pre-record: 1~30s / Post-record: 10~300s

Record Modes
Manual, Schedule (Continuous, MD (Motion Detection), Alarm, IVS)

Recording Resolution
Configurable from: 24.0MP (6016 x 4016) to D1 (704 x 480)

Remote View
iOS (iPhone,iPad), Android Devices

Search Modes
Time / Date, Alarm, MD & Exact Search (to the second)

Series
Professional AI Series Recorders

Stranger Mode
Detect strangers face (not in database)

Trigger Events
Alarm Out, Video Push, Email, Recording, PTZ, Tour, Snapshot, Voice Prompt , Buzzer & Screen Tips

Trigger Events (Face Recognition)
Buzzer, Voice Prompts, Email, snapshot, Recording, Alarm Out, PTZ activation, etc.

Two-way Talk
1 Channel Input, 1 Channel Output, RCA

USB Interface
3 x USB Ports (2 x Rear USB 3.0, 1 x Front USB 2.0)

Vehicle
Vehicle colour, vehicle model, vehicle logo, plate colour, vehicle decorations, call, seatbelt

Video Compression
H.265+ / H.265 / H.264+ / H.264 / MJPEG

Video Detection
Motion Detection, MD Zones: 396 (22 x 18), Video Loss, Tampering & Scene Change

Video Input
32 channels

Video Output
2 x HDMI, 1 x VGA

Weight
5.00kg (without HDD)

Warranty (Years)
4



Technical Documents

Download documents from the following links:
