Shop » Products » LED Lighting » High Bays » AVOL 100W Driver-on-Board LED High Bay Light
200W Driver-on-Board LED High Bay Light
Sale!
200W Driver-on-Board LED High Bay Light
200W Driver-on-Board LED High Bay Light

AVOL 100W Driver-on-Board LED High Bay Light

Original price was: $109.00.Current price is: $84.25.

(Guest - Inc. GST)
Register for Member Pricing

4 Interest Free Payments of $21.06

AVOL 100W Driver-on-Board LED High Bay Light – LED Lighting > High Bays

Add to wishlist

SKU: LHB-E100-C Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

The AVOL LHB-E Series high bay lights deliver energy efficient lighting to commercial applications. They are built with a weather resistant housing and IK07 rated vandal resistant tampered glass lens. Each light has a compact, robust aluminium body and comes in a cool white colour temperature.

The LHB-E series delivers ideal lighting conditions in areas with high ceilings, such as warehouses, sporting facilities and exhibition halls.

Product features:
• 100W LED flood light with 10000lm light output
• High 100lm/W luminous efficacy for energy efficiency
• 6000K cool white colour temperature
• 90° beam angle
• Slim economical design, and aluminum construction
• IK07 rated vandal resistant strong tempered glass lens
• IP65 rated weather resistance for outdoor use
• Long lifespan LED lighting: rated for up to 35,000 hours
• Integrated, on-board LED driver for streamlined installation

Specifications

Optical
Light Output
10000lm
Luminous Efficacy
100lm/W
Colour Temperature
6000K
Colour Rendering Index
> 80
Beam Angle
90°
Light Decay
N/A
Rated Lifespan
35,000 hours
Electrical
Power Consumption
100W
Input Voltage
220 ~ 240VAC
Power Factor
> 0.9
Dimmable
N/A
Motion Activated
N/A
General
Ingress Protection
IP65
Plug / Socket / Base
3-Pin AC Plug
Reflector / Diffuser
Tempered glass lens
Housing Adjustments
180° adjustable housing
NSW ESS Accepted
No
Operating Environment
-20° ~ 50°C
Dimensions
Ø260 x 50mm
Other
Vandal Resistance
IK07
Warranty (Years)
3
Register for Member Pricing



Technical Documents

Download documents from the following links:

LHB-E Series LED High Bays Installation Guide (PDF)

AVOL_LHB-E_Series_High_Bays_Datasheet_PDF

LHB-E100-C – IES File for Lighting Simulation
