Shop » Products » Residential Intercom » 4G Intercom » LTE 4G Door Intercom – Keypad – 2 doors – 500 apartments – Slave
AN2106M 12K
Sale!
4G Capable
LTE 4G Door Intercom - Keypad - 2 doors - 500 apartments - Slave - Image 3
LTE 4G Door Intercom - Keypad - 2 doors - 500 apartments - Slave - Image 4
LTE 4G Door Intercom - Keypad - 2 doors - 500 apartments - Slave - Image 5
LTE 4G Door Intercom - Keypad - 2 doors - 500 apartments - Slave - Image 6
LTE 4G Door Intercom - Keypad - 2 doors - 500 apartments - Slave - Image 7

LTE 4G Door Intercom – Keypad – 2 doors – 500 apartments – Slave

Original price was: $1,410.00.Current price is: $1,375.00.

Register for Member Pricing

4 Interest Free Payments of $343.75

4G CapableEliminate cables with this LTE 4G door audio intercom with keypad for up to 500 apartments.  Set the intercom to call up to 3 numbers per apartment. Supports 1000 pin codes for access.  Requires master unit – AN1206M-12K

SKU: AN2106S-12K Category: Tags: , , , , ,
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

4G CapableThe Aristel AN2106S 12K 4G LTE Door Intercom is an expansion unit for the AN1206S-12K multi-function system designed to eliminate the cost of expensive cabling when installed in existing apartments or retirement complexes. The intercom supports up to 500 apartments and has an LCD screen for ease of use. The slave unit which allows for the same SIM to be used for multiple doors on the same property. The Master intercom uses a 4G SIM card and supports all networks.  The master and slave are interconnected with a 9 conductor cable to allow the slave unit to use the master 4G radio for calls.

Product Features

  • Illuminated keypad
  • Intercom can call up to 3 numbers sequentially to each of 500 apartments.
  • Remote access control of 2 gates or doors.
  • Up to 1152 authorized guests can activate the door release by calling the intercom.
  • Door open with PIN code
  • Supports 1000 PIN codes for staff access.
  • IP54 rated
  • Set up via SMS/Smartphone APP/PC
  • Dimensions – Face of intercom: 138w x 262h
  • Dimensions – Surface mount box: 177w x 324h x 71d
  • Anti Vandal & Aluminium Design
  • Requires master unit.



Register for Member Pricing

Specification

Intercom Features

  • Supports calling up to 500 villas or apartments
  • 2 Relays for access control.
  • Programmable timers for ring time, door open / closed time.
  • Access control by up to 1152 authorized guests by free call to intercom.
  • 1000 PIN codes for keypad entry access
  • Intercom can be called for silent monitoring.

Register for Member Pricing

Interconnect parameters

  • input terminals for egress button
  • 2 relays, each with NO/NC contacts
  • Inbuilt rectifier bridge enables AC or DC operation on 12-24 volts.
  • Adjustable speaker and microphone levels.
  • Network signal strength check by SMS.
  • Operating temperature -20C to 50C
  • Includes 2 9 pin plugs and header cable for interconnection with the master

Security

  • Administrator only has SMS and dial in access for changing settings
  • Log of guests’ arrival times can be SMS to administrator
Register for Member Pricing

Physical properties

  • 1 hotline programmable button. (Speed dial, Intercom etc.)
  • Operates on 12-24 volt AC or DC
  • Dimensions – Face of intercom: 138w x 262h
  • Dimensions – Surface mount box: 177w x 324h x 71d
  • Rainhood and in & On wall mounting brackets ARE Included

Register for Member Pricing

Download the brochure from the link below.

AN2106-12K-Brochure

AN2106-12K-4G-User-Guide

Register for Member Pricing

Intercom-SS2106M-12K-Panel operation
