2N® IP Verso - main unit with camera, keypad, mount, silver
Sale!
2N® IP Verso - main unit with camera - silver

2N® IP Verso – main unit with camera, keypad, mount, silver

Original price was: $2,546.50.Current price is: $2,540.01.

(Guest - Inc. GST)
Register for Member Pricing

2N IP Verso – Silver with mechanical keypad and mount – complete system. Note you must select the mounting system for purchase – default is surface mount

SKU: AX9155101C-KB Categories: , Tags: , , , ,
Free Shipping for orders over $600 (AU Only)*
Brand: ,

Description

Please Note:  This unit can only be purchased with the appropriate surface or flush mount -default surface mount included in price.

This Verso Intercom includes the 2N IP Verso Main Unit with Camera (silver) and the 2N IP Verso keypad module (silver) and your choice of surface or flush mounting frame.

The 2N® IP Verso security intercom is configurable to your needs thanks to its modularity. It provides reliable access control and allows you to easily interface with other systems. This version is bundled with the silver mechanical keypad and must be purchased with the surface or flush mount frame.

Suitable for:
Offices and office buildings
Residential complexes
Family houses
Schools and campuses
State administration public
buildings
Home Automation
Hotels
Other options available with the modular Verso system include:

Bluetooth technology

Get the latest technology in access systems. The Bluetooth module lets you eliminate access codes, entry cards, and key distribution.

Touch screen

Register for Member Pricing

Create an intuitive and structured contact list similar to that in your mobile phone. It is water resistant vandal resistant and easy to read even in direct sunlight.

Camera with night vision

See who is standing in front of your door, even in total darkness. Moreover, the camera is hidden from normal view. The intruder has no clue they’re being monitored.

Features and Benefits

Register for Member Pricing

Adjustable door security levels
Make use of different security modes with the 2N® Mobile Key application, which allows you to adjust the functioning distance from the Bluetooth module

Intuitive controls and search
The touchscreen has all the functions of a mechanical keyboard. Discover its luxury design and intuitive controls and search

Access control
Achieve a greater level of security for all those at its location. 2N® IP Verso makes it easy to prevent the entry of unauthorized persons.

Register for Member Pricing

Modularity
The modularity of this IP Intercom allows you to configure it to your requirements. Select the specific module, accessories and configurable functions.

SIP support with no server needed
SIP protocol support makes it easy to link the intercom with IP phones and PBX from other producers, without having to connect to the server.

Register for Member Pricing

Security relay
This simple additional device prevents intrusion by detecting any unauthorized manipulation of the electronic locking system.

Picture to email
2N® IP Verso allows you to email snapshots of the visitor captured by the camera at the time of the call.

Integration to the security system
Easily link the intercom to the existing security system and increase site security.

Register for Member Pricing

Specifications

Camera Unit

Signalling protocol
SIP 2.0 (RFC – 3261)
Buttons
ButtonsTransparent buttons with white backlight and easily removable label
Number of buttons1 to 146
Numeric keypadOptional
Audio
Microphonebuilt-in
Speaker1x2W integrated
Sound pressure at 1 kHz
at 1 m distance		78 dB
Audio stream
CodecsG.711, G.729, G.722, L16/16kHz
Camera
Resolution – JPEG1280 x 960 px
Resolution – video call640 x 480 px
Viewing angle120° (H), 90° (V), 145° (D)
Night visionYes
Bluetooth module (optional)
Bluetooth Smart technology
SecurityRSA-1024 and AES-128
Touchscreen (optional)
Buttons and keyboard functions
Video stream
CodecsH.263+, H.263, H.264, MJPEG, MPEG-4
RFID card reader
RFID card reader13.56MHz and 125kHz
Support for NFCYes, HCE and the 2N® Mobile Key application needed
Interfaces
Power supply12V ± 15%/ 2A DC, or PoE
PoEPoE 802.3af (Class 0 – 12.95W)
LAN10/100BASE-TX with Auto-MDIX, RJ-45
Switch outputNC/NO contacts, max 30 V/1 A AC/DC
Active switch output8 to 12 V DC depending on Power supply (PoE: 10 V; adapter: source voltage minus 2 V), max 400mA
Supported protocolsSIP2.0, DHCP opt. 66, ONVIF, SMTP, 802.1x, RTSP, RTP, TFTP, HTTP, HTTPS, Syslog
Mechanical properties
Operating temperature-40°C – 60°C, touch display -30°C – 60°C
Storage temperature-40°C – 70°C
Operating relative humidity10%-95% (non-condensing)
Coverage levelIP 54, IK08, touch display IK07
Dimensions
Dimensions depend on configuration of the modules and installation type – see www.2n.cz for details.

Keypad Module

Number of Buttons12
BacklitVia white LEDs
Operating temperature range-40°C ~ 60°C
Protection levelIP54
Dimensions105(H) x 97(W) x 27(D) mm
Weight (Net)0.40kg
Weight (Gross)0.70kg

Brochure

Download the brochure from the link below.

 Brochure

Video

Integration

2N Intercoms are famous for their ability to integrate with a wide range of different equipment types and applications.  This list is the most common and only represents a small percentage of systems that are proven to interoperate.  A full list is accessable from the link below.

PBX Systems

LogoTested PBXTested VersionInterop
3CX Phone SystemAll Versions(tick)
Alcatel – Lucent OmniPCXOffice5, 6(tick)
Alcatel – Lucent OmniPCXEnterpriseR9.0 h130142(tick)
Asterisk13.8-cert4(tick)
Aura Comm. Manager / Session managerR6.2(tick)
IP Office7.0, 8.0(tick)
IP Office IP 500 V29.0.5.0 build 972(tick)

BroadsoftR17.0, R22.0(tick)
Cisco Call Manager Express4, 7, 8, 9(tick)
Cisco Unified Communications Manager (CallManager)6, 7, 8, 9, 11, 12(tick)
Cisco UC 320W(tick)
Cisco UC 54012.4(tick)
Cisco BE3000(tick)
Cisco BE6000(tick)

Ericsson-LG iPecs LIKv6.0Bo and v6.0Cv(tick)
FreePBX(tick)

Freeswitch1.6.13(tick)
FRITZ!Box 74906.50(tick)
Gigaset T300 PRO(tick)

Kamailio SIP server4.4(tick)
Panasonic NS1000(tick)
Samsung OfficeServ 7000 seriesV4.60b(tick)
Siemens HiPath 3000 V8(tick)
Siemens HiPath 4000 V6(tick)
Siemens OpenStage Gate View(tick)

Skype for BusinessServer: 2015 6.0.9319.259(green star)
Toshiba IPedgeTGZ1.6 0.27 and above(tick)
Toshiba CIXMT069 and above(tick)

Used Symbols

(tick) – Verified with video

(green star) – Verified with audio only

Home and Building Automation

LogoTestedVersionInterop
Control4Composer 2.7.0, Drivers: 2N IP intercom (version 1.10.3.e), Recluse AV HTTP Command Driver(tick)
T3 Series7″ and 10″ In-Wall Touch Screens, 7″ Portable(tick)
Touch Screen (V2)7″ Portable(tick)
InfinityEdge (V1)

Only audio works

5″ and 7″(warning)
Crestron(tick)

ELAN(tick)
HC21.5.2(tick)
Omni Automation Controller3.9 or higher(tick)
OmniTouch71.8 or higher(tick)

RTI Touch Panel KX101.1.10 (KX10)(tick)

Savant SIS-5000(tick)
Savant DOR-xxx-xx(tick)

Thinknx(tick)

Used Symbols

(tick) – Compatible

(warning) – Work with limitation

A full list of interoperability and documentation can be found here: https://wiki.2n.cz/hip/inte/latest/en
